• Aerodynamic multi-reflector halogen headlamps
• Color-keyed outside mirrors
• High Solar Energy-Absorbing (HSEA) glass
• Intermittent front/rear wipers

• Fully-reclining fabric front bucket seats w/driver seat height adjuster
• Split-folding reclining rear bench seats w/slide/tumble/recline/remove functions
• Full cut-pile carpeting
• Multi-function center console-inc: adjustable front/rear cup holders, aux pwr outlet, storage pocket, covered armrest storage compartment
• Instrumentation-inc: speedometer, tachometer, twin tripmeters, coolant temp/ fuel gauges
• Remote hood/fuel filler door releases
• Rear window defogger
• Illuminated entry
• Deluxe AM/FM stereo w/cassette-inc: 4-speakers
• Digital clock
• Fabric-trimmed doors w/map pockets
• Dual sunvisors-inc: vanity mirrors, sliding extensions
• Front maplight
• Cargo area aux pwr outlet
• (6) cargo area grocery bag hooks

• Dual airbag supplemental restraint system (SRS)
• 3-point seat belts for all outboard seating positions
• Front shoulder belt pretensioners w/force limiters
• Adjustable front seat belt anchors
• Rear door child safety locks
• Side-door impact beams

Additional Packages

Qo

• DR
• PG

• Vehicle
• EPA Classification: Sport Utility Vehicle
• Mileage
• EPA Fuel Economy Est - City (MPG): 24
• EPA Fuel Economy Est - Hwy (MPG): 29
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 325
• Maximum Alternator Capacity (amps): 80
• Cooling System
• Total Cooling System Capacity (qts): 8.1
• Weight Information
• Base Curb Weight (lbs): 2777
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 1500
• Dead Weight Hitch - Max Tongue Wt. (lbs): 150
• Suspension
• Suspension Type - Front: MacPherson Strut
• Suspension Type - Rear: Double-Wishbone
• Suspension Type - Front (Cont.): w/Stabilizer Bar
• Suspension Type - Rear (Cont.): w/Coil Springs
• Shock Absorber Diameter - Front (mm): 32
• Shock Absorber Diameter - Rear (mm): 25
• Stabilizer Bar Diameter - Front (in): 0.98
• Stabilizer Bar Diameter - Rear (in): - TBD -
• Brakes
• Brake Type: Pwr
• Brake ABS System: Four-Wheel
• Disc - Front (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 11.8 x 0.71
• Drum - Rear (Yes or ): Yes
• Rear Drum Diam x Width (in): 9.0 x - TBD -
• Tires
• Front Tire Size: P235/60R16
• Front Tire Size: P215/70R16
• Rear Tire Size: P235/60R16
• Rear Tire Size: P215/70R16
• Spare Tire Size: P235/60R16
• Spare Tire Size: P215/70R16
• Wheels
• Front Wheel Size (in): 16 x 7.0
• Front Wheel Size (in): 16 x 6.5
• Rear Wheel Size (in): 16 x 7.0
• Rear Wheel Size (in): 16 x 6.5
• Spare Wheel Size (in): 16 x 6.5
• Front Wheel Material: Aluminum
• Front Wheel Material: Steel
• Rear Wheel Material: Aluminum
• Rear Wheel Material: Steel
• Spare Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr Rack & Pinion
• Steering Ratio (:1), Overall: - TBD -
• Lock to Lock Turns (Steering): - TBD -
• Turning Diameter - Curb to Curb (ft): 35.4
• Turning Diameter - Wall to Wall (ft): - TBD -
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 14.8
• Exterior Dimensions
• Wheelbase (in): 98.0
• Length, Overall (in): 167.1
• Length, Overall (in): 166.2
• Width, Max w/o mirrors (in): 70.3
• Width, Max w/o mirrors (in): 68.3
• Height, Overall (in): 65.7
• Track Width, Front (in): 60.0
• Track Width, Front (in): 59.3
• Track Width, Rear (in): 59.1
• Min Ground Clearance (in): 6.3
• Rear Door Opening Height (in): - TBD -
• Rear Door Opening Width (in): - TBD -
• Liftover Height (in): - TBD -
• Cargo Area Dimensions
• Cargo Area Length @ Floor to Seat 1 (in): - TBD -
• Cargo Area Length @ Floor to Seat 2 (in): - TBD -
• Cargo Area Width @ Beltline (in): - TBD -
• Cargo Box Width @ Wheelhousings (in): - TBD -
• Cargo Box (Area) Height (in): - TBD -
• Cargo Volume to Seat 1 (ft³): 68.3
• Cargo Volume to Seat 2 (ft³): 29.2
• Interior Dimensions
• Passenger Capacity: 5
• Passenger Volume (ft³): - TBD -
• Front Head Room (in): 39.6
• Front Head Room (in): 41.3
• Front Leg Room (in): 42.4
• Front Shoulder Room (in): 54.1
• Front Hip Room (in): 53.4
• Second Head Room (in): 38.3
• Second Leg Room (in): 32.6
• Second Shoulder Room (in): 53.7
• Second Hip Room (in): 46.5
• Summary
• Vehicle Name: Toyota RAV4
• Vehicle Name: Toyota RAV4
• Body Style: 4 Door
